Zoe Scanner Disassembly
Summary
This training video explains how to properly disassemble the Aetrex Zoe Scanner for safe packing and shipping.
You will learn how to disconnect the scanner from the fixture, remove each of the four cameras, and place them correctly in the Zoe shipping box to prevent damage during transport.
Following these steps ensures the equipment is packed safely and is ready to be sent for service, relocation, or replacement.
Steps
-
Disconnect the USB cable from the base of the scanner fixture.
-
Remove the rear white plastic cover from the camera housing.
-
Press the black release button located behind the camera.
-
While pressing the button, carefully slide the camera out of the fixture.
-
Place the camera into the designated protective slot inside the Zoe shipping box.
-
Repeat this process for the remaining three cameras until all four cameras are removed.
-
Once all cameras are removed, securely organize them inside the Zoe box to prepare the scanner for shipping.
