This video is a tutorial that guides the user through setting up the Albert 2 Pro scanner in two easy steps. It asks users not to proceed without watching the brief tutorial. Step one is to unbox the scanner , and it includes a list of the box contents. Step two shows how to connect all four cameras. The video provides detailed instructions for the correct camera installation, including matching the numbers on the tower and the base , how to connect the USB cable without pinching it , and how to check that the cable is fully plugged in. Once the camera setup is complete, the Albert 2 Pro scanner is ready for connection with the computer and the MODI fixture. Users are asked to scan a QR code or click on a link to proceed to the next connection video.

Steps

The video outlines the scanner setup in two main steps:

Step 1: Unbox Your Scanner

The box contents include:

• Four camera towers.

• USB cable lock.

• A power adapter.

• The scanner base.

• An information card with a QR code leading to training videos and webinars.

Step 2: Connect All Four Cameras

1. Ensure the number on the bottom of each camera tower matches the number on the camera base.

2. Remove the back plate from the camera tower by gently pulling up from the bottom.

3. Insert the camera posts into the camera base.

4. Take care not to pinch the USB cable.

5. Gently push down on the camera tower until you hear the button click.

6. Connect the USB cable.

7. Before placing the cover back on, double-check the top camera connection.

• If the silver plug is visible (the connection is unsecured), gently push the cable fully into the camera.

8. Now replace the camera tower cover, starting at the top and gently popping it into place.

9. Repeat the process for the other three cameras.
